Plan B Interior
The following
scans are from the original brochure. I left the as fairly
large file sizes, hopefully ok for printing
|
Line Drawing
Floor Plan A |
Sail Plan
Floor
Plan B |
Click for
original CL Ad from 1968
|
Some
Pictures of members Clipper 36's
"Walkabout"
|
Deck
Pic from brochure
Salon
of "Jamcill"
|
The 36 was in
production from 1969 to about 1988. The 36 came with 100 gal glass water tank, and
60 gal fuel tank. According to the original brochure the 36 could be purchased with
either diesel or gas engines. Our 36 has a 37 HP Westerbeke 4-107 diesel. Also
the 36 was available in two floor plans
and came either as Schooner or Ketch
rigged. The 36
was built to Lloyds 100A1 Specs.
The 36 was built with Sitka Spruce spars and had an external hung ballast of cast iron.
